DS-7608/7616NI-Q2/8P(Q2/16P), 8CH 8PoE / 16CH 16PoE H.265 4K NVR up to 8MP Recording, 2 HDD BAY

DS-7608/7616NI-Q2/8P(Q2/16P), 8CH 8PoE / 16CH 16PoE H.265 4K NVR up to 8MP Recording, 2 HDD BAY
$236.00 $299.00
DS-7608NI-Q2/8P

DS-7600NI-Q2/P SERIES, 8CH 8PoE / 16CH 16PoE H.265 UP TO 8MP RECORDING 4K NVR



General Info

1. Hikvision firmware upgradable

2. You may have lead time, so please contact us before you order

3. Contact us for HDD installation options. (sales@vuelabsecurity.com)



Feature

  • Up to 8 IP Cameras(for 8CH NVR), 16 IP cameras(for 16CH NVR) can be connected
  • Support H.265+/H.265
  • Full channel recording at up to 8 MP
  • Supports VCA detection alarm such as face detection, line crossing, intrusion detection and more
  • Smart search for the selected area in the video; and smart playback to improve the playback efficiency
  • HDMI Video output at up to 4K (3840 × 2160) resolution
  • 2 SATA hard disk can be connected with 6TB
  • Hik-Connect
  • 1U Chassis



HIKVISION VALUE SERIES 4K NVR

H.265 DS-7600NI-Q2/P Series 4K Network Video Recorder

8CH 8PoE / 16CH 16PoE Up to 8MP Recording

ModelDS-7608NI-Q2/8P
DS-7616NI-Q2/16P
IP video input8-ch up to 8MP
16-ch up to 8MP
Incoming bandwidth
80 Mbps
160 Mbps
Outgoing bandwidth80 Mbps
80 Mbps
Recording resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
HDMI output resolution
1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 ×
1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 ×
1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA output resolution1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
Audio output
1-ch, RCA (Linear, 1 KΩ) 1-ch, RCA (Linear, 1 KΩ)
Decoding formatH.265/H.265+/H.264/H.264+/MPEG4
H.265/H.265+/H.264/H.264+/MPEG4
Live view / Playback resolution
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/
2CIF/CIF/QCIF
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/
2CIF/CIF/QCIF
Synchronous playback8-ch
16-ch
Decoding Capability1-ch @ 8 MP / 4-ch @ 1080p
1-ch @ 8 MP / 4-ch @ 1080p
Network protocolsTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS,
iSCSI, UPnP™, HTTPS
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS,
iSCSI, UPnP™, HTTPS
SATA2 SATA interfaces
2 SATA interfaces
HDD CapacityUp to 6TB capacity for each disk
Up to 6TB capacity for each disk
Network interface1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
USB interface2 × USB 2.02 × USB 2.0
PoE Interface
8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
PoE Power≤ 80W
≤ 150W
StandardIEEE 802.3 af/at
IEEE 802.3 af/at
Two-way audio
1-ch, RCA (2.0 Vp-p, 1 k Ω)
1-ch, RCA (2.0 Vp-p, 1 k Ω)
Power supply
100 to 240 VAC
100 to 240 VAC
Power
≤ 180W
≤ 280W
Consumption
(without hard disk)
≤ 15W
≤ 15W
Working temperature
10 to +55º C (+14 to +131º F)
10 to +55º C (+14 to +131º F)
Working humidity
10 to 90 %10 to 90 %
Chassis1U chassis 1U chassis
Dimensions (W × D × H)385 × 315 × 52 mm (15.2"× 12.4" × 2.0")
385 × 315 × 52 mm (15.2"× 12.4" × 2.0")
Weight (without hard disk)≤ 2.6 kg (5.7 lb)
≤ 2.6 kg (5.7 lb)
