DS-7104/7108NI-Q1/4P/M(Q1/8P/M), 4CH 4PoE / 8CH 8PoE H.265 NVR up to 4MP Recording, 1 HDD BAY

DS-7104/7108NI-Q1/4P/M(Q1/8P/M), 4CH 4PoE / 8CH 8PoE H.265 NVR up to 4MP Recording, 1 HDD BAY
$99.00 $150.00
DS-7104NI-Q1/4P/M

DS-7100NI-Q1/P/M SERIES, 4CH 4PoE / 8CH 8PoE H.265 UP TO 4MP RECORDING NVR



General Info

1. Hikvision firmware upgradable

2. You may have lead time, so please contact us before you order

3. Contact us for HDD installation options. (sales@vuelabsecurity.com)



Feature

  • Up to 4 IP Cameras(for 4CH NVR), 8 IP cameras(for 8CH NVR) can be connected
  • Support H.265+/H.265
  • Full channel recording at up to 4 MP
  • Supports line crossing and intrusion detection
  • Smart search for the selected area in the video; and smart playback to improve the playback efficiency
  • One-key operation: automatically search, modify and add IP cameras after device is activated
  • HDMI/VGA output at 1080p resolution
  • 1-ch playback at 4 MP resolution or 2-ch at 1080p resolution
  • 1 SATA hard disk can be connected with 6TB
  • Hik-Connect
  • 48VDC





HIKVISION VALUE SERIES NVR

H.265 DS-7100NI-Q1/P/M Series Network Video Recorder

4CH 4PoE / 8CH 8PoE Up to 4MP Recording

ModelDS-7104NI-Q1/4P/M
DS-7108NI-Q1/8P/M
IP video input4CH up to 4MP Resolution
8CH up to 4MP Resolution
Incoming bandwidth40 Mbps
60 Mbps
Outgoing bandwidth60 Mbps60 Mbps
Recording resolution4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
HDMI/VGA output resolution
1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Decoding formatH.265+/H.265/ H.264+/H.264
H.265+/H.265/ H.264+/H.264
Live view / Playback resolution
4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Synchronous playback4CH
8CH
Capability
1-ch @ 4 MP / 2-ch @ 1080p1-ch @ 4 MP / 2-ch @ 1080p
Network protocolsTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,UPnP™
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,UPnP™
SATA1 SATA interface
1 SATA interface
CapacityUp to 6TB capacity for each diskUp to 6TB capacity for each disk
Network interface1, RJ-45 10/100Mbps self-adaptive Ethernet interface
1, RJ-45 10/100Mbps self-adaptive Ethernet interface
USB interface2 × USB 2.0
2 × USB 2.0
Interface4, RJ-45 10/100 Mbps self-adaptive Ethernet interface
8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power≤ 36W≤ 75W
Standard
IEEE 802.3 af/at
IEEE 802.3 af/at
Power supply48 VDC
48 VDC
Power≤ 50W
≤ 90W
Consumption
(without hard disk and PoE)
≤ 10 W
≤ 10 W
Working temperature
-10 to +55º C (+14 to +131º F)
-10 to +55º C (+14 to +131º F)
Working humidity10 to 90 %
10 to 90 %
Chassis1U chassis
1U chassis
Dimensions (W × D × H)
260 × 225 × 48 mm (10.2" × 8.9" × 1.9")
260 × 225 × 48 mm (10.2" × 8.9" × 1.9")
Weight(without hard disk)
≤ 1 kg (2.2 lb)≤ 1 kg (2.2 lb)
